Industrial X-Ray Non-Destructive Inspection Power Supply
American High Voltage provides high-voltage power supply for X-ray non-destructive inspection equipment. We have the capacity to satisfy requirements for OEM and laboratory applications, meeting size and voltage specifications for a variety of in-field inspection units.
Our experience enables us to meet a range of commercial inspection needs. We have developed, designed, and manufactured more than 1,000 custom power supplies. This includes designs for mass spectrometry, analytical X-rays, and digital radiography systems. Power supply modules range from 100V up to 200kV and 1W up to 1kW.
Our team places a strong focus on dependable service. Over 40 years of experience has helped us understand the schedule and pricing needs of commercial customers in the non-destructive inspection industry. We have more than 200 standard power supplies and DC converters often available within just a few weeks. And excel at designing and building custom solutions to fit specific needs.
Typical Industry Power Supply
High Temperature X-ray HVPS
Output Voltage: 100kV
Operating Temperature (Case): Up to 175 Degree Celsius
Voltage Programming
Integrated Floating Filament
Designed to withstand severe & harsh enviroments
NTR-100kV Neutron Generator HVPS (Regulated)
NTP-100kV Neutron Generator HVPS (Proportional)
Encapsulated design to withstand Shock and Vibration Environments
Voltage Inputs: 24VDC, 48VDC, 100VDC, 150VDC, 200VDC
Voltage Output: -100kVDC
Max Power: 10W
Operating Temperature: Up to 175 Degree Celsius
Size: >1.30”OD, 1.50”OD
Features: Voltage and Current Monitor, Voltage Control
HAQ
Output proportional to input
Encapsulated and Shielded
Long Lifetime @ 185 Degree Celsius
Output Voltages: 500VDC, 1000VDC, 2000VDC, 2500VDC & 3000VDCW
Power: 1.5W
Operating Temperature: 185 Degree Celsius Continuously
Designed to withstand severe and harsh environments
H-25B/HTC/HTR/HTDR
Regulated Positive or Negative Polarity
Encapsulated and Shielded
Long Lifetime @ 200 Degree Celsius
Output Voltages: 500VDC, 1000VDC, 2000VDC, 2500VDC & 3000VDC
Operating Temperature: 200 Degree Celsius Continuously
Designed to withstand severe and harsh environments
High Temperature Multiple-Output Low Voltage DC Converters
High Temperature DC-DC Converter
Encapsulated and Shielded
Input Voltage: 200VDC
Output Voltages: +/-3.3VDC, +/-5VDC, +/-15VDC, +/-18VDC
Operating Temperature: 185 Degree Celsius Continuously
Designed to withstand severe and harsh environments
Miniature High Temperature HVPS for Ultrasonic Transducers
Input Voltage: +15VDC
Encapsulated and Shielded HVPS output: Up to 500VDC
Operating Temperature: 175 Degree Celsius Continuously
Dimension: 2.75” Length x 1.00” Width x 0.50” Height
Operating Temperature: 185 Degree Celsius Continuously
Designed to withstand severe and harsh environments
