Mini-Sized High Voltage Power Supply and Converter Modules
Mini-sized high voltage power supplies come in a range of output options. Choose from AC waveform output, bipolar output, or floating filament output. We offer modules with both proportional voltage-in to voltage-out output and regulated output. For those with battery operated applications, we have high efficiency, high voltage power supplies.
We even have compact designs with reliable high voltage or DC to AC power conversion. These modules can be easily included where space is limited. And as expected from American High Voltage, all modules include safety features that align with their various output options.
Mini-Sized Series
AC Series
AC Output (Quasi-Sine Wave) Proportional to Input
Output Voltage: AC series are available in multiple AC output voltages ranging from 50V to 4,000V peak to peak
Power: 1.5W, 3W, 5W
Dimension: 2.50” x 1.50” x 0.75”
CT Series
Center-Tapped Modules
Output Proportional to Input
Output Voltage: CT series are available in multiple output voltages ranging from +/-50VDC to +/-2,500VDC
Dimension: 2.50” x 1.00” x 0.75”
EC Series
Output Proportional to Input
Output Floating up to 20kVDC
Output Voltage: EC series are available in multiple output voltages ranging from +/-6.3VDC to +/-5,000VDC
Power: 5W
Dimension: 3.50” x 1.50” x 0.61”
SC Series
Output Proportional to Input
Output Voltage: SC series are available in multiple output voltages ranging from 50VDC to 15,000VDC
Power: 1.5W, 3W, 5W, 10W
Dimension: 2.50” x 1.00” x 0.75”
SCR Series
Regulated
Output Voltage: SCR series are available in multiple output voltages ranging from +/-50VDC to +/-5,000VDC
Power: 5W
Dimension: 2.50” x 1.00” x 0.75”
SQ Series
Output Proportional to Input
High Efficiency
Output Voltage: SQ series are available in multiple output voltages ranging from +/-500VDC to +/-3,000VDC
Power: 1W
Dimension: 2.50” x 1.00” x 0.75”
Product Categories
Micro-Sized Modules
Micro-sized power supply and DC converters for compact, miniature, and ultra-miniature high voltage output
Mini-Sized Modules
Mini-sized power supply and DC converters for compact and miniature high voltage output
Mil-Spec Modules
Military grade high voltage power supplies to meet the demands of harsh environments and extreme temperatures
High Temperature Modules
High Voltage power supplies and DC-to-DC converters for high temperature applications, such as oil well or borehole logging
Ultra-Thin Modules
Ultra-thin power supplies and DC converters for ultra-compact and severe environment applications
High Power Modules
High power supply modules for either high voltage applications or low cost power supply
Half Rack Units
Half Rack resonant switching power supply, ideal for laboratory use, converts AC power to regulated, high voltage DC power that can be programmed and monitored.
Custom High Voltage Power Supply
Custom design, prototype, and production of high voltage power supply units, specializing in meeting severe temperature and harsh environment requirements
