Military Spec Power Supply

Trusted by multiple military programs, American High Voltage has provided military spec power supplies for more than 30 years. Our power supplies and voltage converters have been part of the F-4 and F-16 aircrafts, space shuttles, and more. We have the expertise to upgrade power supplies with non-existent or very little documentation.

We design and manufacture military power supplies for both high and low voltage. We perform all required potting, component preparation, and placement among other critical requirements. Our military spec power supplies go through rigorous environmental stress screening and derating.

We have the experience and facilities to meet military standards and specifications. From design to sourcing to manufacturing and testing, our mil spec programs meet Department of Defense registration and compliance. Every power supply and converter meets strict performance standard for reliability, and every project is designed to meet delivery and economic requirements. From our multi-function display power supply to miniature CRT power supply to heads up display power supply, we have repeatedly proven our ability to meet military demands.

Typical AHV Military Power Supply Designs

Multi-Function Display Power Supply

Anode Output: 22kVDC @ 0.5mA
Focus Output: 4kVDC @550uA
G2 Output: 550VDC @ 50uA

Miniature CRT Power Supply

Anode Output: 7kVDC @ 250µA
Focus Output: 1.2kVDC @ 200µA
Dimension: 2.5” x 2.4” x 0.25”

Helmet Mounted Display HVPS Basic Specification

Anode Output: 8.5kVDC @ 50uA
Focus Output: 1.2kVDC @ 50uA
Grid Output: 700VDC @ 5uA
Dimension: 3.80” x 1.20” x 1.00”

Heads Up Display Power Supply

Anode Output: 18kVDC @ 310µA
Focus Output: 4.5kVDC @ 490µA
G2 Output: 890VDC @ 10µA
300V, 500 kHz DC coupled Dynamic Focus
Multiple Low Voltage Outputs:
LV Output 1: +5V @ 1.2A
LV Output 2: +/- 6.3V @ 430mA
LV Output 3: +/- 15V @ 300mA
LV Output 4: +60V @ 15mA
LV Output 5: -50V @ 200uA
Dimension: 6.2” x 6” x 2.25”

Some examples of our qualified U.S. Military power supply:

NSN	AHV Part Number	Application
6130-01-025-1537 6130-01-025-1538 6130-01-011-0559 6130-01-032-6013 6130-01-033-5068 6130-01-101-1931 6130-01-164-1267 6130-01-391-8419 6130-01-408-0384 6130-01-408-0386 6130-01-408-6610 6130-01-412-3824 6130-01-490-6324 6130-01-492-6327 6130-01-518-9683 WF 6130-01-544-5687 WF 6130-01-585-9805 WF	580008 580352 SF-50A SF-14V SLR-15 801155-1 G-12 10-FDD-001T M-12N M-10 SW-25 SLR-13 M-120 SF-6V 580395 580470 580717	F-4 Radar Anode F-4 Radar Focus Various CRT Focus Various Ground CRT Displays Multi-Output CRT Supply Adjustable 12KV, Various Systems CRT Anode, Various Naval Radar Display Naval Radar Display 25 KV Anode, Various Displays Multi-Output CRT Supply Ground Radar Display Ground Radar Display F-4 Radar Focus F-16 MFD Multi-Output F-16 Heads Up Display F-16 Low Voltage Power Supply
