High Temperature Power Supply, High Temperature DC Converter


American High Voltage specializes in high temperature DC converters and power supplies for clients in a wide range of industries. We’re a worldwide leader in custom-designed high temperature power supplies and DC converters and produce a number of standard and custom products to stand up to harsh environments with extreme temperatures. From converters for downhole oil and gas applications to power supplies for avionics applications, we produce products to meet the needs of your specific industry.

Our High temperature DC converters and power supplies are the result of over 35 years’ experience in the design of 200°C rated products. We qualify and derate our high temperature components significantly for the application.  Our standard and custom high temperature power supplies range from 2.5V up to 150kV and, in some instances, they can withstand temperatures of up to 225°C.

The High Temperature X-ray HVPS, the 100kV Neutron Generator HVPS, the 2kV PMT power supply, the 100V Ultrasonic Transducer power supply and the High Temperature Multiple-Output Low Voltage DC Converters are just a few of the options available. However, we customize products to fit any applications you require and deliver them in a timely fashion.

Contact American High Voltage at 775-777-0992 today or email us to obtain one of the high temperature DC converters and power supplies we have in stock or to custom order.


AHV offers a wide range of both Standard and Custom High Temperature power supplies.



High Temperature X-ray HVPS
Output Voltage:
100kV
Operating Temperature (Case): Up to 175 Degree Celsius
Voltage Programming
Integrated Floating Filament
Designed to withstand severe & harsh enviroments



NTR-100kV Neutron Generator HVPS (Regulated)
NTP-100kV Neutron Generator HVPS (Proportional)

Encapsulated design to withstand Shock and Vibration Environments
Voltage Input:
24VDC, 48VDC, 100VDC, 150VDC, 200VDC
Voltage Output: -100kVDC
Max Power: 10W
Operating Temperature: Up to 175 Degree Celsius
Size: <1.30"OD, 1.50”OD
Features: Voltage and Current Monitor, Voltage Control



HAQ
Output proportional to input
Encapsulated and Shielded
Long Lifetime @ 185 Degree Celsius
Output Voltage: 500VDC, 1000VDC, 2000VDC, 2500VDC & 3000VDC
Power: 1.5W
Operating Temperature: 185 Degree Celsius Continuously
Designed to withstand severe and harsh environments.



H-25B/HTC/HTR/HTDR
Regulated Positive or Negative Polarity
Encapsulated and Shielded
Long Lifetime @ 200 Degree Celsius
Output Voltage:
500VDC, 1000VDC, 2000VDC, 2500VDC & 3000VDC
Operating Temperature: 200 Degree Celsius Continuously
Designed to withstand severe and harsh environments.



High Temperature Multiple-Output Low Voltage DC Converters
High Temperature DC-DC Converter
Encapsulated and Shielded
Input Voltage:
200VDC
Output Voltages: +/-3.3VDC, +/-5VDC, +/-15VDC, +/-18VDC
Operating Temperature: 185 Degree Celsius Continuously
Designed to withstand severe and harsh environments.



Miniature High Temperature HVPS for Ultrasonic Transducers
Input Voltage: +15VDC
Encapsulated and Shielded HVPS output: Up to 500VDC
Operating Temperature: 175 Degree Celsius Continuously
Dimension: 2.75” Length x 1.00" Width x 0.50" Height
Designed to withstand severe and harsh environments.
