Military Power Supply


Several different military programs value and trust the high and low voltage military power supplies produced by American High Voltage. For more than thirty years, we provided both high and low voltage military power supplies to a wide range of military platforms, including F-4 and F-16 aircrafts, space shuttles, and more. Outside of designing custom power supplies for military programs, we specialize in upgrading power supplies with non-existent or very little documentation.

There are different processes in creating high and low voltage military power supplies. Designing and manufacturing high voltage power supplies requires certain disciplines and technological controls above and beyond what is required when designing and manufacturing low voltage devices. Potting, component preparation, and placement are just a few of the most critical requirements. We design and manufacture both high and low voltage military power supplies by putting them through a program of rigorous environmental stress screening and derating.

We’re fully committed to meeting the performance, reliability, delivery, and economic requirements of the most demanding military programs. We’ve proven repeatedly by manufacturing the Multi-Function Display Power Supply, the Miniature CRT Power Supply, and the Heads Up Display Power Supply.

Give American High Voltage a call at 775-777-0992 today or email us for additional information on our high and low voltage military power supplies.




Typical AHV Military Power Supply Designs

Multi-Function Display Power Supply
Anode Output:
22kVDC @ 0.5mA
Focus Output: 4kVDC @550uA
G2 Output: 550VDC @ 50uA



Miniature CRT Power Supply
Anode Output: 7kVDC @ 250µA
Focus Output: 1.2kVDC @ 200µA
Dimension: 2.5” x 2.4” x 0.25”



Helmet Mounted Display HVPS Basic Specification
Anode Output: 8.5kVDC @ 50uA
Focus Output: 1.2kVDC @ 50uA
Grid Output: 700VDC @ 5uA
Dimension: 3.80” x 1.20” x 1.00”



Heads Up Display Power Supply
Anode Output: 18kVDC @ 310µA
Focus Output: 4.5kVDC @ 490µA
G2 Output: 890VDC @ 10µA
300V, 500 kHz DC coupled Dynamic Focus
Multiple Low Voltage Outputs:

LV Output 1: +5V @ 1.2A
LV Output 2: +/- 6.3V @ 430mA
LV Output 3: +/- 15V @ 300mA
LV Output 4: +60V @ 15mA
LV Output 5: -50V @ 200uA
Dimension: 6.2” x 6” x 2.25”





Some examples of our qualified U.S. Military power supply:



NSN

6130-01-025-1537
6130-01-025-1538
6130-01-011-0559
6130-01-032-6013
6130-01-033-5068
6130-01-101-1931
6130-01-164-1267
6130-01-391-8419
6130-01-408-0384
6130-01-408-0386
6130-01-408-6610
6130-01-412-3824
6130-01-490-6324
6130-01-492-6327
6130-01-518-9683 WF
6130-01-544-5687 WF
6130-01-585-9805 WF

AHV Part Number

580008
580352
SF-50A
SF-14V
SLR-15
801155-1
G-12
10-FDD-001T
M-12N
M-10
SW-25
SLR-13
M-120
SF-6V
580395
580470
580717
Application

F-4 Radar Anode
F-4 Radar Focus
Various CRT Focus
Various Ground CRT Displays
Multi-Output CRT Supply
Adjustable 12KV, Various Systems
CRT Anode, Various
Naval Radar Display
Naval Radar Display
25 KV Anode, Various Displays
Multi-Output CRT Supply
Ground Radar Display
Ground Radar Display
F-4 Radar Focus
F-16 MFD Multi-Output
F-16 Heads Up Display
F-16 Low Voltage Power Supply
